ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve

ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve

  • ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve
  • ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve
  • ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve
  • ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve
ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve
تفاصيل المنتج:
مكان المنشأ: الصين
اسم العلامة التجارية: Brando
إصدار الشهادات: CE
رقم الموديل: G353A045
شروط الدفع والشحن:
الحد الأدنى لكمية: 1 جهاز كمبيوتر
الأسعار: قابل للتفاوض
تفاصيل التغليف: الصناديق الداخلية والكرتون والمنصات النقالة
وقت التسليم: التفاوض
شروط الدفع: ل / c، / تي تي، ويسترن يونيون
القدرة على العرض: 100000 جهاز كمبيوتر في الشهر
اتصل
مفصلة وصف المنتج
يكتب: صمام الحجاب الحاجز نوع الزاوية اليمنى قوة: هوائي
وسائط: هواء حجم الميناء: 1-1/2 بوصة 1.5 بوصة
بناء: غشاء مادة الجسم: سبائك الألومنيوم
مادة الحجاب الحاجز: NBR (شائع) ، FKM (متاح) عدد الغشاء: 1
ضغط: 0.1 إلى 0.8mpa درجة حرارة: -25 إلى +80 ℃
إبراز:

Pulse Valve G353A045,1.5'' Pulse Jet Valve,Pulse Diaphragm Valve

,

1.5'' Pulse Jet Valve

,

Pulse Diaphragm Valve

ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve


Single Stage, remote pilot, threaded body pulse valve.

The ASCO Type diaphragm pulse valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to provide reliable and economical operation.

ASCO series 353 pulse valves are especially designed for dust collector service applications, combining high flow, long life and an extremely fast opening and closing to produce reliable and a economical operation. The valves comes with silencers to help reduce noise and prevent foreign particles from entering the valve.

ASCO Product Reference: G353A045


Technical Data of ASCO Pulse Jet Valve:


Port
Size
Remote Pilot Connection
Office Size
Operating Pressure Differential (Bar)
Model Number
Diaphragm Material
G
φB
(mm)
Min.
Max.
Aluminium



NBR/Viton
3/4''
1/8''
24
0.35
8.5
G353A041
1''
1/8''
27
0.35
8.5
G353A042
1 1/2''
1/8''
52
0.35
8.5
G353A045



Main Dimension:

ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve 0


353 Series Pulse Jet Valve For Dust Collector System:


Right Angle Valve
3/4''
1''
1 1/2''
2''
2 1/2''
SCG353A043
SCG353A044
SCG353A047
SCG353A050
SCG353A051
Submerged Valve
3''
SCEX353.060
Remote Pilot Valve
3/4''
1''
1 1/2''
G353A041
G353A042
G353A045


Our Production:

ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve 1


Related Products:

ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve 2 ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve 3 ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve 4 ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve 5
Pneumatic Fitting Diaphragm Remote Pilot Box Pulse Controller



Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing


Welcome to your any question and inquiry!
