RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V

RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V

  • RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V
  • RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V
  • RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V
RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V
تفاصيل المنتج:
مكان المنشأ: الصين
اسم العلامة التجارية: Brando
إصدار الشهادات: None
رقم الموديل: RCA3D
شروط الدفع والشحن:
الحد الأدنى لكمية: 1 جهاز كمبيوتر
الأسعار: قابل للتفاوض
تفاصيل التغليف: الصندوق الداخلي ، الكرتون ، البليت
وقت التسليم: من 4 إلى 7 أيام عمل
شروط الدفع: / تي تي، بايبال، ويسترن يونيون
القدرة على العرض: 100000 قطع شهريا
اتصل
مفصلة وصف المنتج
حجم المنفذ: 1/8 '' نوع الخيط: NPT ، BSPP
هيكل الصمام: الزاوية اليمنى ، منفذ الخيوط مادة الختم: NBR ، FKM
نطاق ضغط العمل: 0 إلى 0.85 ميجا باسكال لفائف الجهد: 12VDC ، 24VDC ، 24VAC ، 110VAC ، 220VAC
إبراز:

GOYEN RCA3D,RCA3D pilot valves,rca3 solenoid pilot valves

,

RCA3D pilot valves

,

rca3 solenoid pilot valves

RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V


Solenoid pilot valves are specifically designed for the reverse pulse jet filter cleaning of dust collectors and baghouses. These include all variations of bag filters, cartridge filters, envelope filters, ceramic filters and sintered metal fiber filters. Their tough and reliable construction makes them perfectly suited for both noxious and environmental dust collection applications in a wide range of industries, including:


1. Cement dust collection
2. Mining dust collection
3. Silo/bulk materials handling dust collection
4. Industrial dust collection
5. Power industry: protection of boilers and gas turbine intake filter systems


Ordering Code of RCA3D Solenoid Pilot Valve:

Model
Port Size
Coil Type
Voltage
Power
RCA3D0-330
(Old RCA3D2-T-QT/1392B)
1/8''
Screw / Spade
200/240V 50/60Hz
17.4/22.6VA
RCA3D0-331
(Old RCA3D2-T-QT/1004B)
100/120V 50/60Hz
15.2/149.7VA
RCA3D0-332
24V 50/60Hz
23.1/17.2VA
RCA3D0-333
240V DC
24W
RCA3D0-334
110V DC
24W
RCA3D0-335
48V DC
20W
RCA3D0-336
(Old RCA3D2-T-QT/764B)
24V DC
20W
RCA3D0-337
(Old RCA3D2-T-QT/1295B)
12V DC
20W
RCA3D1-330
1/8'' BSPP
200/240V 50/60Hz
17.4/22.6VA
RCA3D1-331
100/120V 50/60Hz
15.2/149.7VA
RCA3D1-332
24V 50/60Hz
23.1/17.2VA
RCA3D1-333
240V DC
24W
RCA3D1-334
110V DC
24W
RCA3D1-335
48V DC
20W
RCA3D1-336
24V DC
20W
RCA3D1-337
12V DC
20W


Main Dimension of RCA3D Solenoid Pilot Valve:

RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V 0


Video of RCA3D Solenoid Pilot Valve:


Enclosure for RCA3D Solenoid Pilot Valve:

RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V 1


More Goyen Type Pulse Valves for you to choose:

RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V 2 RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V 3 RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V 4 RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V 5
T Series DD Series FS Series MM Series
RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V 6 RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V 7 RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V 8 RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V 9
RCA Series Solenoid Coil Solenoid Armature Diaphragm


Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!
