Name: Diaphragm Repair Kit For 2'' DMF-Z-50S DMF-Y-50S DMF-T-50S SBFEC Type Old Version Pulse Jet Valve
Brand: Ningbo Brando Hardware Co., Ltd
SKU: LD50
Price: 49.10 USD
Availability: InStock

منزل المنتجات طقم إصلاح الحجاب الحاجز

Diaphragm Repair Kit For 2'' DMF-Z-50S DMF-Y-50S DMF-T-50S SBFEC Type Old Version Pulse Jet Valve

تفاصيل المنتج:

مكان المنشأ:	نينغبو، الصين
اسم العلامة التجارية:	BRANDO
إصدار الشهادات:	None
رقم الموديل:	LD50

شروط الدفع والشحن:

الحد الأدنى لكمية:	1 مجموعة
الأسعار:	قابل للتفاوض
تفاصيل التغليف:	كيس بلاستيك ، صندوق ، كرتون ، منصة نقالة
وقت التسليم:	من 4 إلى 7 أيام عمل
شروط الدفع:	/ تي تي، ويسترن يونيون، بايبال
القدرة على العرض:	100000 مجموعة في الشهر

اتصل

مفصلة وصف المنتج

اسم المنتج:	الصمام الحاجز للنبض	مادة الحجاب الحاجز:	النتريل ، Viton
مادة المقعد:	المطاط ، النايلون	1 مجموعة:	1x غشاء كبير ، 1x غشاء صغير ، 2x نوابض
حجم منفذ صمام النبض المناسب:	2 ''	نموذج صمام النبض المجهز:	DMF-Z-50S، DMF-Y-50S، DMF-T-50S
إبراز:	DMF-Z-50S Pulse Valve Membrane Kit,DMF-Y-50S Pulse Valve Membrane Kit,SBFEC Pulse Valve Membrane , DMF-Y-50S Pulse Valve Membrane Kit , SBFEC Pulse Valve Membrane

Diaphragm Repair Kit For 2'' DMF-Z-50S DMF-Y-50S DMF-T-50S SBFEC Type Old Version Pulse Jet Valve

Diaphragm (Membrane) for Old Version 2'' BFEC pulse valve DMF-Z-50S, DMF-Y-50S, DMF-T-50S; NBR material is standard, working temperature range is -5 to +80 ℃; Viton material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse valves are operated by integral solenoid pilot operator. When the valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pilot operated valve is de - energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the valve.

Ordering Number of Diaphragm For SBFEC Pulse Valve:

Diaphragm For New Version BFEC Pulse Valves
Diaphragm Order Code	Fitted Pulse Valve Model	Valve Port Size
DTY (Secondary Diaphragm)	All Double Diaphragm Pulse Valves	/
D20A	DMF-Z20	3/4''
	DMF-ZM-20
D20B	DMF-ZL-B	3/4''
D25	DMF-Z-25	1''
	DMF-ZM-25
	DMF-Y-25
	DMF-T-20	3/4''
D40	DMF-Z-40S	1-1/2''
	DMF-Y-40S
	DMF-ZF-40S
	DMF-ZM-40S
	DMF-T-25S	1''
D50	DMF-Z-50S	2''
	DMF-Y-50S
	DMF-T-50S
D62	DMF-Z-62S	2-1/2''
	DMF-Y-62S
	DMF-T-62S
D76	DMF-Z-76S	3''
	DMF-Y-76S
D102	DMF-Z-102S	4''
	DMF-Y-102S
D102A	DMF-Y-102SA	4''
D300	DMF-N-300	12''
Diaphragm For Old Version BFEC Pulse Valves
LD50	DMF-Z-50S (Old)	2''
	DMF-Y-50S (Old)
	DMF-T-50S (Old)
LD62	DMF-Z-62S (Old)	2-1/2''
	DMF-Y-62S (Old)
	DMF-T-62S (Old)
LD76	DMF-Z-76S (Old)	3''
	DMF-Y-76S (Old)

Main Dimension of LD50 Diaphragm For Old Version BFEC Pulse Valve:

Diaphragm Repair Kit For 2'' DMF-Z-50S DMF-Y-50S DMF-T-50S SBFEC Type Old Version Pulse Jet Valve 0

Video of LD50 Membrane For Old Version BFEC Pulse Valve:

Pictures of Pulse Valve Diaphragm Production:

Diaphragm Repair Kit For 2'' DMF-Z-50S DMF-Y-50S DMF-T-50S SBFEC Type Old Version Pulse Jet Valve 1

More Related Products For you to choose:


Right Angle Type	Quick Mount Type	Straight Through Type	Submerged Type

Valve Diaphragm	Solenoid Coil	Solenoid Armature	Pulse Controller

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
