AIRTAC Type Solenoid Valves Air Valves 4V220-06 AC220V 110V DC12V 24V

AIRTAC Type Solenoid Valves Air Valves 4V220-06 AC220V 110V DC12V 24V

5/2 way pneumatic solenoid valves are used for controlling double acting pneumatic cylinders. They have 2 output ports, commonly designated A & B or 2 & 4. They have one inlet port, designated P or 1, and two exhaust ports, designated R & S or 3 & 5.

In one position, inlet port P or 1 is connected to output port A or 2, while the port B or 4 is exhausted through exhaust port S or 4. This means the pneumatic cylinder is extended.

In the other position of the valve, P or 1 is connected to port B or 4, and port A or 2 is connected to the exhaust port R or 3. This means the cylinder is retracted.

The valve is shifted from one position to the other by various means; for example, a couple of solenoids or pilot connections. Many a time, one default position is achieved by means of a spring and the other through a solenoids or a pilot connection.

Data of 4V200 Series Pneumatic Solenoid Valves:

Dimension of 4V220-06 Pneumatic Solenoid Valve:

Production Video of Pneumatic Solenoid Valves:
